Industry Pneumatic Duty Air Hydraulic Riveter LE-AR0102
(1) Efficient And Durable Riveting Operations
(2) Pneumatic And Hydraulic Control Systems
(3) Ergonomic Design For Easy Operation
(4) Versatile Application In Various Scenarios
(5) Application Scope: Manufacturing, Construction, Transportation, Electronics Manufacturing, Furniture Manufacturing.
The Compact Precision Air Hydraulic Riveter
The ultimate ultra-lightweight solution for high-frequency industrial fastening. Engineered to eliminate operator fatigue while maintaining laboratory-grade joint integrity.
I. The Fatigue Factor: Why Ergonomics is a Strategic Asset
In high-throughput manufacturing lines—from electronics assembly to furniture crafting—repetitive fastening is the primary source of operator strain. Traditional heavy riveters lead to Cumulative Trauma Disorders (CTD) and micro-delays in work cycles.
"Joint integrity is the silent insurance of your production line. If your tools induce fatigue, you are building in structural debt through human error."
The LEMATEC Compact Air Hydraulic Series is designed to bridge the gap between power and comfort. By utilizing an optimized pneumatic-hydraulic hybrid system, it provides the traction required for 4.8mm rivets while weighing only 0.40kg—the lightest in its industrial class.
Ergonomic Precision Control
Human-Centric Engineering: Designed for maximum accessibility in densely packed industrial components.
Precision Engineering in Taiwan: Optimized for 24/7 industrial assembly cycles.
II. Technical Procurement Data
Reliability is a result of consistent specifications. The following technical profile ensures this tool meets global MRO (Maintenance, Repair, and Operations) standards.
| Model Number | Compact Duty Series |
|---|---|
| Rivet Capacity | 2.4, 3.2, 4.0, 4.8 mm |
| Stroke Length | 10 mm (3/8") |
| Vibration Level | 3 m/s² (Low Hand-Arm Stress) |
| Air Consumption | 5.8 CFM (Average) |
| Overall Length | 147 mm (Ultra-Compact) |
| Air Inlet Thread | 1/4" NPT / PT Universal |
| Net Weight | 0.40 kg (0.88 lbs) |
III. Multi-Sector Implementation Matrix
The compact chassis allows for deep access in high-density assemblies across four key sectors:
B2B Strategic OEM Partnership
LEMATEC provides end-to-end manufacturing support for global tool brands looking to differentiate their catalog with Taiwan-made precision.
- ✅ Custom Branding: Laser engraving & bespoke colors.
- ✅ Bulk Logistics: 25 PCS / Carton efficiency.
- ✅ Sample Readiness: Technical units for engineering audits.
- ✅ Export Support: Global shipping from Taiwan.
© 2026 LEMATEC. All rights reserved. Precision Fastening Innovation from Taiwan to the World.
I. Technical Procurement Profile
The LE-AR0102 is a professional pneumatic-hydraulic tool engineered for high-frequency industrial use. The following technical data ensures compatibility with global MRO standards.
| Model Identifier | LE-AR0102 |
|---|---|
| Traction Power | 1045 kg.f (2303 Lbs.f) @ 85 PSI |
| Effective Stroke | 16 mm (0.63") |
| Air Consumption | 1.48 Liter / Cycle |
| Working Pressure | 78 – 85 PSI (5.5 – 6.0 kg/cm²) |
| Applicable Nose Pieces | 2.4, 3.2, 4.0, 4.8 mm |
| Air Inlet Thread | 1/4" PT / NPT Universal |
| Net Tool Weight | 1.50 kg (3.3 lbs) |
▲ Precision Core: Integrated hydraulic conversion system ensuring 0% traction drop.
II. Professional Operation & Setup Protocol
To maximize the tool's 30,000-cycle lifespan, follow the standardized industrial setup logic below:
▲ Standard Operating Procedure: Optimized for Downtime Mitigation.
III. Engineering Detail & Logic
Strategic Note: The LE-AR0102 utilizes a high-impact polymer base combined with a forged steel head, delivering the agility of a lightweight tool with the durability of a heavy-duty hydraulic station.
